You have just completed Lesson 4, which:
Demonstrated the steps to read a Map PanelDescribed the elements found on most Map Panels- Floodplain Boundaries
- Hazard Area Designation
- Base Flood Elevation
- Flood Zone Division Line
- Flood Insurance Risk Zone Designations
- North Arrow
- Stream Lines
- Coastal Barrier Symbol
- Area Not Included Label
- Map Scale
- Panel Number
- Notes to User
- Elevation Reference Marks (ERMs)
Identified elements specific to Flood Boundary and Floodway Map (FBFM) and Flood Insurance Rate Map (FIRM) Map Panels- Alpha-numeric Grid
- Cross Section Symbol
- Floodway Boundaries
- Floodway Designation
Identified elements Found Only on Some FBFM/FIRM Panels for Individual Communities:- Initial Identification Date
- FHBM Revisions Chronology
- Map Effective Date
Identified elements Found Only on Countywide Panels- Effective Date of Countywide Map Panel
- Map Number
